DS-7604NI-K1(D)

IP video input : 4-ch Up to 8 MP resolution

Incoming bandwidth : 40 Mbps

Outgoing bandwidth : 80 Mbps

HDMI output : 1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz

VGA output : 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

Video output mode : HDMI/VGA simultaneous output

Audio output : 1-ch, RCA (Linear, 1 KΩ)

Two-way audio input : 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)

Decoding format : H.265+/H.265/H.264+/H.264

Recording resolution : 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Network protocol : TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS

SATA : 1 SATA interface

Capacity : Up to 8 TB capacity for each disk
